4 Wire Condenser Fan Motor Variable Speed , HVAC Condenser Motor
(0
reviews)
Inhouse product
Price
AED 0.00
/Pc
Share
Top Selling Products
Reviews & Ratings
0.00
out of 5.0
(0
reviews)
There have been no reviews for this product yet.
Product application:
Condenser and condenser unit, window type air conditioner.
Product features:
1. 100% pure copper motors.
2. Reasonable structure, high efficiency, low-temperature rise, low noise, small vibration.
3. Use NSK low noise high-quality rolling bearing.
4. Nickel plating for shaft, electrophoretic coating for the enclosure.
Product specification:
Electrical parameters:
| Model | YDK-375-4Ax |
| Output Power | 1/2HP |
| Full load Amps | 3.1A |
| Frequency | 60Hz |
| Voltage | 208-230V |
| Speed | 825/1075/1550RPM |
| Insulation class | B |
| Structure | ball bearing, with capacitor |
Outline Dimension:
| Total length | 10-5/16″ |
| Shaft length | 4-1/2″ |
| Shaft diameter | 1/2″ |
| Screw diameter | 5-1/8″ |
| Body diameter | 5-5/8″ |
| Screw qty | 4 |
| Screw size | 8-32NC-2A |
